With an easy release liner maintaining the integrity of your graphics, SLX Cast Wrap will allow you to get more wraps out the door with less manpower. The superior repositionability of SLX Cast Wrap + FLITE Technology® provides a long-term bond where it counts: deep channels, complex curves, and rivets. Outperforming other films, your customers will love their visually striking wraps and you’ll love the easy and clean removability.
Ideal for full or partial vehicle and fleet wraps, and large decals.
Fast, easy application for the novice and experienced installers.
Vibrant and reliable print quality on Eco-Solvent, Solvent, UV and Latex print systems.
Easy liner release maintaining the integrity of the graphic.
Property | Test Methods | Typical Value | |
---|---|---|---|
Surface Finish | Gloss Meter 60° Reflection | 70 to 90 Gloss Units | |
Thickness | Micrometer, Federal Bench Type | 2-mil (50 micron) | |
Tensile Strength | Tensile Tester with 2-in (51 mm) jaw separation; crosshead speed of 12 in/min. (5.1 mm/s), web direction | ≥ 4.5 lb/in | ≥ 0.8 kg/cm |
Elongation | Instron Tensile Tester as above | Average 190% | |
Shelf Life (In Box) | Ideal Storage Temperature 70°F (21°C) and 50% relative humidity | 2 years from factory shipment | |
Application Temperature Range | On clean, dry substrate | 40°F to 100°F | 4.4°C to 38°C |
Application Temperature Range | On clean, dry substrate (corrugated with rivets and channels) | 60°F to 100°F | 15°C to 38°C |
Service Temperature Range | On clean, dry substrate | -40°F to 176°F | -40°C to 80°C |
Dimensional Stability | 158°F (70°C), 48 hours | 0.010 in | 0.24 mm |
Peel Adhesion | PSTC-1, 15 min, 70°F (21°C) | ≥ 2.4 lb/in | ≥ 420 N/m |
Peel Adhesion | PSTC-1, 24 hours, 70°F (21°C) | ≥ 3.0 lb/in | ≥ 525 N/m |
Peel Adhesion | PSTC-1, 1 week, 70°F (21°C) | ≥ 4.2 lb/in | ≥ 736 N/m |
Liner Release | TLMI Release at 90˚, 300 in/min (760 cm/min) | 50 g/2 in | 9.84 g/cm |
Liner Weight | On a clean, dry substrate | 0 | 0 |
