Ideal for indoor applications, Gravostrat™ is resistant to chemical products and solvents. It is also non-flammable and non-conducting.Gravostrat™ is perfect for industrial and
military applications. It is phenolic, layered composition ensures that you get the perfect quality when engraving using CO2 lasers.Gravostrat™ is very rigid and is saw cut. Gravostrat™ can be lazered (engraving but not cutting). Gravostrat™ may be subject to slight variations in thickness.
Phenolic material
• Low glare
• Resistant to chemicals and solvents
• Non-flammable
• Conforms to military specifications
ASTM D 709 ES-1, ES-2, ES-3
• Electrically non-conductive
Specifications
Finish : Low Glare
Composition: Rigid Thermoset material
Depth of engraving : 0.012 "
Full sheet : 36 "x 39"
Half sheet : 18 "x 39"
Quarter sheet : 18 "x 19.5"
Indoor | ■ |
Outdoor | - |
Shear | - |
Saw | ■ |
Screen printing | ■ |
Hot stamping | ■ |
Hot bending | - |
Scratch-resistant | ■ |
Flexible | - |
Break resistant | - |
UV resistant | - |
Min. temperature | -40 ° F |
Max. temperature | 180 ° F |
Making Badges
Making Business Cards
First row of product numbers are 1/16" thickness
Second row of product numbers are 1/8" thickness
White / Black
80194
80195
Yellow / Black
80191
80196
Red / White
80193
80198
Black / White
80192
80197
